Odyssey H2400

Fresh air at the touch of a button

H2400 is an easy-to-use manually controlled whole of home ventilation system.  You decide when you want to introduce fresh cool air into your home by using the simple ‘ON/OFF’ switch. With the ability to exchange the air in your homes living spaces up to five times per hour, the H2400 will help your home remain cool, fresh and dry all year round.


Available from Bunnings stores nationwide  for RRP $999.


Features of H2400:

  • Whole of home Ventilation
  • Wall mounted control switch
  • DIY installation
  • 6 air changes per hour
  • 2400 m3/hr flow rate


Supply only is RRP $999 not including installation.


Running costs per system are $60/pa.


Available nationwide from  Bunnings stores

Technical specifications of H2400

Nominal system diameter: 400 mm
Electrical: 240 VAC 50 Hz
Max. 55 W
Ventilator: Hybrid (natural & powered) backward curved centrifugal
Motor: Electronic Commutating (EC) brushless motor
Turbine/Impeller diameter: 500 mm
Flow Rate @ ΔpsF=0: 2400 m3/hr
Noise SPL @ 2m: 36.5 dB(A)
Roof Slope Installation Range: 3° to 35°
Roof Space Minimum Height: 0.25 m (600mm rafter spacing & 450mm rafter spacing)
Roof Space Maximum Height: 2.25 m (600mm rafter spacing & 450mm rafter spacing)
Ducting: 2 m Flexible metallised polyester film with helix wire support
Grille: Return air type with magnetically detachable grille
Wall mounted control panel: 11cm Mechanical on/off switch
Sensor accuracy Sensors not included
ACH (Air Changes per Hour) 6

Available in four popular colours to match most roofs:

Odyssey Surfmist


Odyssey Headland


Odyssey Woodland Grey

Woodland Grey®

Odyssey Night Sky

Night Sky®

The COLORBOND® steel colour swatches and images shown on this website have been reproduced to represent actual product colours as accurately as possible. However, we recommend checking your chosen colour against an actual sample of the product before purchasing as varying light conditions and limitations of the printing process may affect colour tones. COLORBOND®, BlueScope, ™ and ® Colour names are registered trademarks of BlueScope Steel Limited.
